Schneider Electric Prekidač ComPacT NSX160 DC PV, 160 A, 1000 V, TM-D zaštitna jedinica, 4P;C16F4TM160D1
Circuit breaker, ComPacT NSX250 DC PV, 10kA/1000VDC, 4 poles, TM-DC PV trip unit 250A...
Cena bez pdv-a: 40.259,95 |
Cena sa pdv-om: 48.311,94 |
Circuit breaker, ComPacT NSX250 DC PV, 10kA/1000VDC, 4 poles, TM-DC PV trip unit 250A
| range | ComPacT new generation |
|---|---|
| device short name | NSX400 DC PV |
| product name | ComPacT NSX new generation |
| device application | Distribution |
| poles description | 4P |
| product or component type | Circuit breaker |
| neutral position | Left |
| network type | DC |
| protected poles description | 4D |
| [In] rated current | 250 A at 40 °C |
| [Ui] rated insulation voltage | 1000 V DC conforming to EN/IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 8 kV |
| [Ue] rated operational voltage | 1000 V DC |
| breaking capacity code | F |
| breaking capacity | 10 kA Icu at 1000 V DC L/R = 2 ms conforming to EN/IEC 60947-2 |
| [Ics] rated service breaking capacity | 10 kA at 1000 V DC conforming to EN/IEC 60947-2 |
| utilisation category | Category A |
| trip unit name | TM-DC |
| trip unit technology | Thermal-magnetic |
| trip unit rating | 250 A at 40 °C |
| protection type |
Overload protection (long time) Short-circuit protection (magnetic) |
| pollution degree | 3 conforming to IEC 60664-1 |
| suitability for isolation | Yes conforming to EN/IEC 60947-2 |
| control type |
Toggle Rotary handle Extended rotary handle |
|---|---|
| mounting mode | Fixed |
| mounting support | Backplate |
| upside connection | Front |
| downside connection | Front |
| mechanical durability | 5000 cycles |
| electrical durability | 1000 cycles 1000 V DC In conforming to EN/IEC 60947-2 |
| connection pitch | 45 mm |
| connections - terminals | 4 screw type terminals aluminium/copper |
| local signalling | Positive contact indication |
| contact position indicator | Yes |
| neutral protection setting | Ir |
| long time pick-up adjustment type Ir | Adjustable |
| long time pick-up adjustment range | 0.7...1 x In |
| long time delay adjustment type | Fixed |
| short-time delay adjustment type | Fixed |
| instantaneous pick-up adjustment type Ii | Adjustable |
| instantaneous pick-up adjustment range | 2.5...5 x In |
| overvoltage category | Class II |
| height | 225 mm |
| width | 185 mm |
| depth | 110 mm |
| net weight | 8.4 kg |
| standards | EN/IEC 60947 |
|---|---|
| product certifications |
CCC EAC Marine |
| IP degree of protection | IP40 conforming to IEC 60529 |
| IK degree of protection | IK07 conforming to IEC 62262 |
| ambient air temperature for operation | -35…70 °C |
| ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 10.0 kg |
| Package 1 Height | 30.0 cm |
| Package 1 width | 30.0 cm |
| Package 1 Length | 40.0 cm |
| range | ComPacT new generation |
|---|---|
| device short name | NSX400 DC PV |
| product name | ComPacT NSX new generation |
| device application | Distribution |
| poles description | 4P |
| product or component type | Circuit breaker |
| neutral position | Left |
| network type | DC |
| protected poles description | 4D |
| [In] rated current | 250 A at 40 °C |
| [Ui] rated insulation voltage | 1000 V DC conforming to EN/IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 8 kV |
| [Ue] rated operational voltage | 1000 V DC |
| breaking capacity code | F |
| breaking capacity | 10 kA Icu at 1000 V DC L/R = 2 ms conforming to EN/IEC 60947-2 |
| [Ics] rated service breaking capacity | 10 kA at 1000 V DC conforming to EN/IEC 60947-2 |
| utilisation category | Category A |
| trip unit name | TM-DC |
| trip unit technology | Thermal-magnetic |
| trip unit rating | 250 A at 40 °C |
| protection type |
Overload protection (long time) Short-circuit protection (magnetic) |
| pollution degree | 3 conforming to IEC 60664-1 |
| suitability for isolation | Yes conforming to EN/IEC 60947-2 |
| control type |
Toggle Rotary handle Extended rotary handle |
|---|---|
| mounting mode | Fixed |
| mounting support | Backplate |
| upside connection | Front |
| downside connection | Front |
| mechanical durability | 5000 cycles |
| electrical durability | 1000 cycles 1000 V DC In conforming to EN/IEC 60947-2 |
| connection pitch | 45 mm |
| connections - terminals | 4 screw type terminals aluminium/copper |
| local signalling | Positive contact indication |
