Schneider Electric Voltage release, TeSys GV4, MX coil, 220 to 240VAC 50Hz, 208 to 277VAC 60Hz; GV4AS287
Voltage release, TeSys GV4, MX coil, 220 to 240VAC 50Hz, 208 to 277VAC 60Hz; GV4AS287...
VAT-exclusive price: 8.492,00 |
VAT-inclusive price: 10.190,40 |
Voltage release, TeSys GV4, MX coil, 220 to 240VAC 50Hz, 208 to 277VAC 60Hz; GV4AS287
| Range | TeSys |
|---|---|
| Device short name | MX |
| Product or component type | Voltage release |
| Device application | Control |
| Range compatibility |
TeSys (TeSys GV4) TeSys (TeSys BV4) |
| Voltage release type | Shunt trip release |
| [Uc] control circuit voltage |
277 V AC 60 Hz 220...240 V AC 50 Hz 208...240 V AC 60 Hz |
| [Ui] rated insulation voltage | 277 V conforming to IEC 60947-1 |
|---|---|
| Threshold tripping voltage |
0.7...1.1 Un failsafe opening < 0.7 Un possible opening |
| Impulse duration | >= 20 ms |
| Mounting mode | Internal mounting |
| Maximum inrush power in VA | 6 VA |
| Maximum hold-in power consumption in VA | 10 VA |
| Mechanical durability | 20000 cycles |
| Operating time | < 50 ms |
| Connections - terminals | Spring terminals 1 0.5…1.5 mm² - cable stiffness: flexible without cable end |
| Wire stripping length | 8 mm |
| Quantity per set | Set of 1 |
|---|
