Schneider Electric Standardno MKS raskidač, Compact NSXm, nazivni napon 12 VDC;LV426850
Standard shunt trip release MX, ComPacT NSXm, 12VDC...
Price on request
Standard shunt trip release MX, ComPacT NSXm, 12VDC
| range | ComPact |
|---|---|
| device short name | MX |
| product or component type | Voltage release |
| device application | Control |
| range compatibility |
ComPacT NSXm new generation ComPact NSXm PowerPact B |
| voltage release type |
Opening coil Shunt trip release |
| control type | Standard |
| [Uc] control circuit voltage | 12 V DC |
| Operating threshold | 0.7 Un opening |
|---|---|
| response time | < 50 ms |
| control signal type |
Maintained Impulse |
| impulse duration | >= 20 ms |
| auxiliary connection terminal | Spring |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 60.0 g |
| Package 1 Height | 1.5 cm |
| Package 1 width | 5.7 cm |
| Package 1 Length | 6.3 cm |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Weight | 600.0 g |
| Package 2 Height | 8.8 cm |
| Package 2 width | 13.0 cm |
| Package 2 Length | 18.5 cm |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 120 |
| Package 3 Weight | 7.2 kg |
| Package 3 Height | 30.0 cm |
| Package 3 width | 30.0 cm |
| Package 3 Length | 40.0 cm |
