Schneider Electric Spojni kabl XZ - muški ravni M12 4-pinski -ženski zglobni M12 4-pinski - PUR 2m;XZCR1512041C2

Jumper cable XZ, male straight M12 4 pin, female elbowed M12 4 pin, PUR 2 m...

Brand: Schneider Electric
Product Code: XZCR1512041C2
Availability: Check availability

VAT-exclusive price: 4.995,00

VAT-inclusive price: 5.994,00

Qnt:

Description
Specification

Jumper cable XZ, male straight M12 4 pin, female elbowed M12 4 pin, PUR 2 m

Main
accessory / separate part category	Cabling accessory
Accessory / separate part type	Jumper cable

Complementary
jumper cable end 1	M12 male 4 pins straight connector with screw-on
jumper cable end 2	M12 female 4 pins elbowed connector with screw-on
cable composition	4 x 0.34 mm²
cable length	2 m
wire insulation material	PUR
cable outer diameter	5.2 mm
[Ue] rated operational voltage	250 V AC 300 V DC
[In] rated current	4 A
insulation resistance	>= 1000 MOhm
maximum resistance across terminals	5000 mOhm
net weight	0.095 kg

Environment
IP degree of protection	IP69K IP67 IP65
product certifications	CULus
ambient air temperature for operation	-35…90 °C static -5…90 °C flexing
ambient air temperature for storage	-35…100 °C

Packing Units
Unit Type of Package 1	PCE
Package 1 Length	16.0 cm
Number of Units in Package 1	1
Package 2 Width	30.0 cm
Package 2 Height	15.0 cm
Package 2 Weight	3.691 kg
Package 1 Width	16.0 cm
Package 1 Height	1.5 cm
Package 1 Weight	84.0 g
Number of Units in Package 2	40
Unit Type of Package 2	S02
Package 2 Length	40.0 cm

Contractual warranty
Warranty	18 months
