Schneider Electric Spacial SF 1 ploča za uvod kablova - fiksiranje spojnicama - 300x600 mm;NSYEC361
Spacial SF 1 entry cable gland plate - fixed by clips - 300x600 mm...
VAT-exclusive price: 8.271,00 |
VAT-inclusive price: 9.925,20 |
Spacial SF 1 entry cable gland plate - fixed by clips - 300x600 mm
| range | Spacial |
|---|---|
| product or component type | Cable gland plate |
| accessory / separate part category | Cable management accessory |
| Anwendung |
Prisma application Multi-purpose |
| range compatibility |
Spacial SF Prisma PH Spacial SFM |
| mounting location | Enclosure bottom |
| cable gland type | Standard |
| cable entry | 1 entry |
| device composition |
Fixing elements 1 plate self extinguishing polyurethane adhesive gasket with cross-section of 15 x 25 mm |
| quantity per set | Set of 1 |
| material | Galvanised steel |
| height | 20 mm |
|---|---|
| width |
300 mm nominal: 116 mm useful: 144 mm real: |
| depth | 600 mm nominal: |
| thickness | 1.5 mm |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 1.72 kg |
| Package 1 Height | 2 cm |
| Package 1 width | 34 cm |
| Package 1 Length | 14.4 cm |
| Unit Type of Package 2 | CAR |
| Number of Units in Package 2 | 1 |
| Package 2 Weight | 2.22 kg |
| Package 2 Height | 2 cm |
| Package 2 width | 34 cm |
| Package 2 Length | 14.4 cm |
| Warranty | 18 months |
|---|
