Schneider Electric Rastavljač Acti9 iSW sa indikatorom - 2P - 20 A - 250V ; A9S61220
switch Acti9 iSW with indicator - 2 poles - 20 A - 250V...
VAT-exclusive price: 1.059,00 |
VAT-inclusive price: 1.270,80 |
switch Acti9 iSW with indicator - 2 poles - 20 A - 250V
| range |
Acti 9
|
|
|---|---|---|
| product name |
Acti 9 iSW
|
|
| product or component type |
Switch disconnector
|
|
| device short name |
ISW
|
|
| device application |
Control
|
|
| poles description |
2P
|
|
| utilisation category |
AC-22A
|
| [Ie] rated operational current |
20 A at 250 V AC 50/60 Hz
|
|
|---|---|---|
| [Ue] rated operational voltage |
415 V AC 50/60 Hz
|
|
| [Ui] rated insulation voltage |
250 V AC 50/60 Hz conforming to IEC EN 60669-1
|
|
| [Uimp] rated impulse withstand voltage |
4 kV
|
|
| control type |
Toggle
|
|
| local signalling |
ON/OFF indication and lamp
|
|
| signalling circuit voltage |
AC: 230 V 50/60 Hz
|
|
| mounting mode |
Fixed
|
|
| mounting support |
DIN rail
|
|
| 9 mm pitches |
2
|
|
| height |
77 mm
|
|
| width |
18 mm
|
|
| depth |
70 mm
|
|
| colour |
White
|
|
| mechanical durability |
300000 cycles
|
|
| electrical durability |
30000 cycles
|
|
| connections - terminals |
Tunnel type terminals - 10 mm² - rigid
Tunnel type terminals - 10 mm² - flexible Tunnel type terminals - 10 mm² - flexible with ferrule |
|
| wire stripping length |
9 mm
|
|
| tightening torque |
1.2 N.m
|
| standards |
IEC EN 60669-1
|
|
|---|---|---|
| IP degree of protection |
IP4
|
|
| pollution degree |
2
|
|
| tropicalisation |
2
|
|
| relative humidity |
95 % at 55 °C
|
|
| ambient air temperature for operation |
-20…50 °C
|
|
| ambient air temperature for storage |
-40…70 °C
|
| Unit Type of Package 1 |
PCE
|
|
|---|---|---|
| Number of Units in Package 1 |
1
|
|
| Package 1 Weight |
68 g
|
|
| Package 1 Height |
2 cm
|
|
| Package 1 width |
8 cm
|
|
| Package 1 Length |
8.5 cm
|
|
| Unit Type of Package 2 |
BB1
|
|
| Number of Units in Package 2 |
12
|
|
| Package 2 Weight |
867 g
|
|
| Package 2 Height |
10 cm
|
|
| Package 2 width |
9 cm
|
|
| Package 2 Length |
24 cm
|
|
| Unit Type of Package 3 |
S03
|
|
| Number of Units in Package 3 |
144
|
|
| Package 3 Weight |
11.281 kg
|
|
| Package 3 Height |
30 cm
|
|
| Package 3 width |
30 cm
|
|
| Package 3 Length |
40 cm
|
| Sustainable offer status |
Green Premium product
|
|
|---|---|---|
| REACh free of SVHC |
Yes
|
|
| EU RoHS Directive |
Compliant
EU RoHS Declaration |
|
| Toxic heavy metal free |
Yes
|
|
| Mercury free |
Yes
|
|
| RoHS exemption information | ||
| China RoHS Regulation |
China RoHS declaration
Pro-active China RoHS declaration (out of China RoHS legal scope) |
|
| Environmental Disclosure | ||
| Circularity Profile | ||
| WEEE |
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
|
| Warranty |
18 months
|
|---|
-
Acti9 iSW & SW A9S61220
