Schneider Electric Prekidač Compact NSXm H (70 kA na 415 VAC), 3P, 100 A Micrologic Vigi 4.1 zaštitna jedinica, kompresione stopice i priključci za
Prekidač Compact NSXm H (70 kA na 415 VAC), 3P, 100 A Micrologic Vigi 4.1 zaštitna jedinica, kompresione stopice i priključci za sabirnice...
VAT-exclusive price: 70.687,13 |
VAT-inclusive price: 84.824,56 |
Prekidač Compact NSXm H (70 kA na 415 VAC), 3P, 100 A Micrologic Vigi 4.1 zaštitna jedinica, kompresione stopice i priključci za sabirnice
| Grupa proizvoda |
Compact
|
|
|---|---|---|
| Ime proizvoda |
Compact NSXm
|
|
| Grupa proizvoda |
Compact NSXm
|
|
| Kratko ime uređaja |
NSXm 100H
|
|
| Tip proizvoda ili komponente |
Diferencijalni prekidač
|
|
| Primena uređaja |
Razvod električne energije
Zaštita |
|
| Number of poles |
3P
|
|
| Opis zaštićenih polova |
3d
|
|
| [in] nazivna struja |
100 A at 40 °C
|
|
| [ue] nazivni napon |
440 V AC 50/60 Hz
|
|
| Tip mreže |
AC
|
|
| Mrežna frekvencija |
50/60 Hz
|
|
| Pogodno za izolaciju |
Yes conforming to EN/IEC 60947-2
|
|
| Kategorija upotrebe |
Kategorija A
|
|
| [Icu] rated ultimate short-circuit breaking capacity |
100 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
70 kA Icu at 380...415 V AC 50/60 Hz conforming to IEC 60947-2 65 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 |
|
| Performance level |
H 70 kA 415 V AC
|
|
| Ime zaštitne jedinice |
Micrologic 4.1
|
|
| Tehnologija zaštitne jedinice |
Elektronska
|
|
| Funkcija zaštitne jedinice |
LSoIR
|
|
| Tip upravljanja |
Ručica
|
|
| Circuit breaker mounting mode |
Zavrtnjima
Sistemom na klik |
| [ui] nazivni napon izolacije |
500 V AC 50/60 Hz
|
|
|---|---|---|
| [uimp] nazivni podnosivi impulsni napon |
8 kV
|
|
| [Ics] rated service short-circuit breaking capacity |
100 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
70 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-2 65 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 |
|
| Mehanička trajnost |
20000 ciklusa
|
|
| Električna trajnost |
10000 cycles at 440 V In
20000 cycles at 440 V In/2 |
|
| Nosači za montažu |
Ploča
DIN šina |
|
| Connection terminals |
stega stopice/sabirnica
|
|
| Povezivanje |
35 mm sa proširivačima
27 mm bez proširivača |
|
| Broj 9 mm modula |
9 module
|
|
| Tip zaštite |
L : for overload protection (thermal)
So : for short time short-circuit protection with fixed delay Trenutna zaštita od kratkog spoja Diferencijalna zaštita |
|
| Veličina zaštitne jedinice |
100 A at 40 °C
|
|
| Long-time pick-up adjustment type Ir (thermal protection) |
Podesivo 9 podešavanja
|
|
| [Ir] long-time protection pick-up adjustment range |
40...100 A
|
|
| Long-time protection delay adjustment type tr |
Fiksno
|
|
| [tr] long-time protection delay adjustment range |
5 sekundi pri 7.2 x Ir
8 sekundi pri 6 x Ir 200 sekundi pri 1.5 x Ir |
|
| Termička memorija |
20 minuta pre i nakon okidanja
|
|
| Short-time protection pick-up adjustment type Isd |
Podesivo, 9 podešavanja
|
|
| [Isd] Short-time protection pick-up adjustment range |
1.5...10 x Ir
|
|
| Short-time protection delay adjustment type tsd |
Fiksno
|
|
| [tsd] Short-time protection delay adjustment range |
0,02 sekundi
|
|
| Instantaneous protection pick-up adjustment type Ii |
Fiksno
|
|
| [Ii] instantaneous protection pick-up adjustment range |
1500 A
|
|
| Diferencijalna zaštita |
Integrisana
|
-
ComPact NSXm LV426792
