Schneider Electric PratiKa industrijski utikač - 16 A - 2P - 20...25 V AC - IP44 ; 82501
PratiKa industrial plug - 16 A - 2P - 20...25 V AC - IP44...
VAT-exclusive price: 1.548,00 |
VAT-inclusive price: 1.857,60 |
PratiKa industrial plug - 16 A - 2P - 20...25 V AC - IP44
| range |
PratiKa
|
|
|---|---|---|
| product or component type |
Plug
|
|
| device short name |
PratiKa plug
|
|
| plug, socket category |
Extra-low voltage
|
|
| poles description |
2P
|
|
| network type |
AC
|
|
| outlet standard |
Industrial
|
| mounting mode |
Wall-mounted
|
|
|---|---|---|
| plug, socket, control station shape |
Angled
|
|
| [In] rated current |
16 A
|
|
| [Ue] rated operational voltage |
20...25 V
|
|
| network frequency |
50/60 Hz
|
|
| plug, socket material |
Self-extinguishing engineering polymer
|
|
| contacts material |
Pins: nickel plated brass
|
|
| connections - terminals |
Captive screws
|
|
| cable cross section |
4…10 mm²
|
|
| cable outer diameter |
6…23 mm
|
|
| thread type |
Pg 21
|
|
| net weight |
0.157 kg
|
|
| base dimension |
70 x 82 mm
|
|
| height |
118 mm
|
|
| width |
70 mm
|
|
| depth |
81 mm
|
|
| colour |
Grey (RAL 7035)
|
|
| voltage colour |
Violet
|
| standards |
EN 60309-1
EN 60309-2 |
|
|---|---|---|
| IP degree of protection |
IP44 conforming to IEC 60529
|
|
| IK degree of protection |
IK08 conforming to EN 62262
|
|
| fire resistance |
850 °C conforming to IEC 60695-2-1
|
|
| relative humidity |
50 % at 40 °C
70 % at 30 °C 90 % at 20 °C |
|
| operating altitude |
2000 m
|
|
| ambient air temperature for operation |
35 °C ( 86400 s )
-25…40 °C |
| Package 1 Weight |
0.300 kg
|
|
|---|---|---|
| Package 1 Height |
0.740 dm
|
|
| Package 1 width |
0.700 dm
|
|
| Package 1 Length |
1.040 dm
|
| Sustainable offer status |
Green Premium product
|
|
|---|---|---|
| EU RoHS Directive |
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration |
|
| Mercury free |
Yes
|
|
| RoHS exemption information | ||
| China RoHS Regulation |
China RoHS declaration
Product out of China RoHS scope. Substance declaration for your information |
|
| Environmental Disclosure |
-
Pratika 82501
