Schneider Electric Podesivi vremenski relej za naponski okidač MN - 100/130 V AC/DC
adjustable time delay relay for MN voltage release, 100/130 VDC, 100/130 VAC 50/60 Hz...
VAT-exclusive price: 69.413,00 |
VAT-inclusive price: 83.295,60 |
adjustable time delay relay for MN voltage release, 100/130 VDC, 100/130 VAC 50/60 Hz
| device short name | MN delay unit |
|---|---|
| product or component type | Time delay relay |
| device application | Control |
| range compatibility |
MasterPact NT Masterpact NW ComPact NSX ComPact NS630b...1600 ComPact NS1600b...3200 PowerPact Multistandard ComPact NSXm ComPact NSX DC Masterpact NW UL 489 Masterpact NT UL 489 Masterpact NW DC |
| voltage release type | Undervoltage release |
| [Uc] control circuit voltage |
100...130 V AC 50/60 Hz 100...130 V DC |
| impulse duration | 200 ms |
|---|---|
| time delay range | 0.5...3 s |
| threshold tripping voltage |
0.35...0.7 Un open 0.85 Un close |
| supply holding power | 4.5 VA |
| supply inrush power | 200 VA |
| mounting mode | External mounting |
| response time |
0.5 s 1 s 1.5 s 3 s |
| accessory / separate part category |
Spare part for Compact NS630b...1600 Spare part for Compact NS1600b...3200 |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 192 g |
| Package 1 Height | 8.3 cm |
| Package 1 width | 7.5 cm |
| Package 1 Length | 9 cm |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 36 |
| Package 2 Weight | 7.31 kg |
| Package 2 Height | 30 cm |
| Package 2 width | 30 cm |
| Package 2 Length | 40 cm |
| EU RoHS Directive |
Compliant
EU RoHS Declaration |
|---|---|
| Mercury free | Yes |
| RoHS exemption information | Yes |
| China RoHS Regulation |
China RoHS declaration
Product out of China RoHS scope. Substance declaration for your information
|
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| PVC free | Yes |
| California proposition 65 | WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Warranty | 18 months |
|---|
-
ComPact NS 33681
