Schneider Electric Motorna prigušnica - 759 A - za frekventne regulatore Altivar - IP00;VW3A5107
motor choke - 759 A - for variable speed drive Altivar - IP00...
VAT-exclusive price: 297.042,00 |
VAT-inclusive price: 356.450,40 |
motor choke - 759 A - for variable speed drive Altivar - IP00
| product or component type | Motor choke |
|---|---|
| range compatibility |
Altivar 71 Altivar Process ATV900 Altivar 61Q Altivar 61 Altivar 71Q Altivar Process ATV600 |
| product specific application | Output filter |
| [In] rated current | 759 A |
| product compatibility |
ATV71HC25N4 ATV61HC25N4 ATV61HC31N4 ATV61HC40N4 ATV61HC50Y ATV61HC63Y ATV61QC31N4 ATV61QC40N4 ATV61QC40Y ATV61QC50Y ATV71HC28N4 ATV71HC31N4 ATV71HC40N4 ATV71HC40Y ATV71HC50Y ATV71QC25N4 ATV71QC31N4 ATV71QC31Y ATV71QC40Y ATV630 variable speed drive wall mount - 250 kW, 380...480 V ATV630 variable speed drive wall mount - 315 kW, 380...480 V ATV930 variable speed drive wall mount - 250 kW, 380...480 V ATV930 variable speed drive wall mount - 315 kW, 380...480 V |
| nedded quantity | 3 |
| electrical connection | Tag connector 2 x M12 |
| maximum motor cable length |
200 m shielded cable P motor 250…355 kW at 380...480 V 1 250 m unshielded cable P motor 250…355 kW at 380...480 V 1 150 m shielded cable P motor 400…630 kW at 500...690 V 1 250 m unshielded cable P motor 400…630 kW at 500...690 V 1 250 m shielded cable P motor 400…630 kW at 500...690 V 2 400 m unshielded cable P motor 400…630 kW at 500...690 V 2 |
|---|---|
| dv/dt |
500 V/µs max at 400 V 750 V/µs max at 500 V 1000 V/µs max at 690 V |
| thermal losses | 598 W |
| maximum drive output frequency | 100 Hz |
| ambient air temperature for operation | -10…50 °C |
| net weight | 93 kg |
| IP degree of protection |
IP20 (with kits VW3A9612,613) IP00 |
|---|---|
| ambient air temperature for storage | -25…70 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 100.5 kg |
| Package 1 Height | 60.0 cm |
| Package 1 width | 75.0 cm |
| Package 1 Length | 80.0 cm |
| Unit Type of Package 2 | P06 |
| Number of Units in Package 2 | 1 |
| Package 2 Weight | 109.0 kg |
| Package 2 Height | 77.0 cm |
| Package 2 width | 80.0 cm |
| Package 2 Length | 60.0 cm |
| Warranty | 18 |
|---|
| product or component type | Motor choke |
|---|---|
| range compatibility |
Altivar 71 Altivar Process ATV900 Altivar 61Q Altivar 61 Altivar 71Q Altivar Process ATV600 |
| product specific application | Output filter |
| [In] rated current | 759 A |
| product compatibility |
ATV71HC25N4 ATV61HC25N4 ATV61HC31N4 ATV61HC40N4 ATV61HC50Y ATV61HC63Y ATV61QC31N4 ATV61QC40N4 ATV61QC40Y ATV61QC50Y ATV71HC28N4 ATV71HC31N4 ATV71HC40N4 ATV71HC40Y ATV71HC50Y ATV71QC25N4 ATV71QC31N4 ATV71QC31Y ATV71QC40Y ATV630 variable speed drive wall mount - 250 kW, 380...480 V ATV630 variable speed drive wall mount - 315 kW, 380...480 V ATV930 variable speed drive wall mount - 250 kW, 380...480 V ATV930 variable speed drive wall mount - 315 kW, 380...480 V |
| nedded quantity | 3 |
| electrical connection | Tag connector 2 x M12 |
| maximum motor cable length |
200 m shielded cable P motor 250…355 kW at 380...480 V 1 250 m unshielded cable P motor 250…355 kW at 380...480 V 1 150 m shielded cable P motor 400…630 kW at 500...690 V 1 250 m unshielded cable P motor 400…630 kW at 500...690 V 1 250 m shielded cable P motor 400…630 kW at 500...690 V 2 400 m unshielded cable P motor 400…630 kW at 500...690 V 2 |
|---|---|
| dv/dt |
500 V/µs max at 400 V 750 V/µs max at 500 V 1000 V/µs max at 690 V |
| thermal losses | 598 W |
| maximum drive output frequency | 100 Hz |
| ambient air temperature for operation | -10…50 °C |
| net weight | 93 kg |
| IP degree of protection |
IP20 (with kits VW3A9612,613) IP00 |
|---|---|
| ambient air temperature for storage | -25…70 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 100.5 kg |
| Package 1 Height | 60.0 cm |
| Package 1 width | 75.0 cm |
| Package 1 Length | 80.0 cm |
| Unit Type of Package 2 | P06 |
| Number of Units in Package 2 | 1 |
| Package 2 Weight | 109.0 kg |
| Package 2 Height | 77.0 cm |
| Package 2 width | 80.0 cm |
| Package 2 Length | 60.0 cm |
| Warranty | 18 months |
|---|
| product or component type | Motor choke |
|---|---|
| range compatibility |
Altivar 71 Altivar Process ATV900 Altivar 61Q Altivar 61 Altivar 71Q Altivar Process ATV600 |
| product specific application | Output filter |
| [In] rated current | 759 A |
| product compatibility |
ATV71HC25N4 ATV61HC25N4 ATV61HC31N4 ATV61HC40N4 ATV61HC50Y ATV61HC63Y ATV61QC31N4 ATV61QC40N4 ATV61QC40Y ATV61QC50Y ATV71HC28N4 ATV71HC31N4 ATV71HC40N4 ATV71HC40Y ATV71HC50Y ATV71QC25N4 ATV71QC31N4 ATV71QC31Y ATV71QC40Y ATV630 variable speed drive wall mount - 250 kW, 380...480 V ATV630 variable speed drive wall mount - 315 kW, 380...480 V ATV930 variable speed drive wall mount - 250 kW, 380...480 V ATV930 variable speed drive wall mount - 315 kW, 380...480 V |
| nedded quantity | 3 |
| electrical connection | Tag connector 2 x M12 |
| maximum motor cable length |
200 m shielded cable P motor 250…355 kW at 380...480 V 1 250 m unshielded cable P motor 250…355 kW at 380...480 V 1 150 m shielded cable P motor 400…630 kW at 500...690 V 1 250 m unshielded cable P motor 400…630 kW at 500...690 V 1 250 m shielded cable P motor 400…630 kW at 500...690 V 2 400 m unshielded cable P motor 400…630 kW at 500...690 V 2 |
|---|---|
| dv/dt |
500 V/µs max at 400 V 750 V/µs max at 500 V 1000 V/µs max at 690 V |
| thermal losses | 598 W |
| maximum drive output frequency | 100 Hz |
| ambient air temperature for operation | -10…50 °C |
| net weight | 93 kg |
| IP degree of protection |
IP20 (with kits VW3A9612,613) IP00 |
|---|---|
| ambient air temperature for storage | -25…70 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 100.5 kg |
| Package 1 Height | 60.0 cm |
