Schneider Electric Izborni prekidač - Ø22 - standardna ručica - 2 pozicije - 1NO+1NC;XA2ED25

Complete selector switch, Easy Harmony XA2, plastic, black, 22mm, 2 positions, stay put, 1NO + 1NC...

Brand: Schneider Electric
Product Code: XA2ED25
Availability: Check availability

VAT-exclusive price: 708,00

VAT-inclusive price: 849,60

Qnt:

Description
Specification

Complete selector switch, Easy Harmony XA2, plastic, black, 22mm, 2 positions, stay put, 1NO + 1NC

Main
range of product	Easy Harmony XA2
product or component type	Complete selector switch
device short name	XA2
bezel material	Plastic
mounting diameter	22 mm

Complementary
sale per indivisible quantity	1
fixing center	>= 30 x 40 mm (panel) - thickness: 1…5 mm
fixing mode	Fixing nut: 2…2.4 N.m
shape of signaling unit head	Round
type of operator	Stay put
operator profile	Black standard handle
operator position information	2 positions
contacts type and composition	1 NO + 1 NC
contact operation	Slow-break
mechanical durability	300000 cycles
connections - terminals	, clamping capacity: <= 2 x 1.5 mm² , clamping capacity: <= 1 x 2.5 mm² , clamping capacity: >= 1 x 0.5 mm² Faston terminals, connection size: 6.3 mm
tightening torque	0.8 N.m
short-circuit protection	10 A fuse type gL conforming to IEC 60269-1
[Ith] conventional free air thermal current	10 A (screw-clamp terminals)
[Ui] rated insulation voltage	600 V conforming to EN 60947-1
[Uimp] rated impulse withstand voltage	6 kV conforming to EN 60947-1
[Ie] rated operational current	3 A at 240 V, AC-15, A600 0.27 A at 250 V, DC-13, Q600
electrical durability	500000 cycles, AC-15, 3 A at 230 V, operating rate <60 cyc/mn, load factor: 0.5 conforming to IEC 60947-5-4 500000 cycles, DC-13, 0.2 A at 110 V, operating rate <60 cyc/mn, load factor: 0.5 conforming to IEC 60947-5-4
electrical reliability	Λ < 10exp(-8) at 24 V
width	30 mm
height	42 mm
depth	68.2 mm
net weight	0.054 kg

Environment
protective treatment	TC
ambient air temperature for storage	-40…70 °C
ambient air temperature for operation	-25…55 °C
overvoltage category	Class I conforming to IEC 536
IP degree of protection	IP65 conforming to IEC 60529
IK degree of protection	IK06 conforming to IEC 60529
standards	GB 14048.1 IEC 60947-1 IEC 60947-5-1 GB 14048.5
product certifications	CCC CE
vibration resistance	10 gn (f= 40…500 Hz) conforming to IEC 60068-2-6
shock resistance	120 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Weight	0.04 kg
Package 1 Height	3.165 cm
Package 1 width	3.338 cm
Package 1 Length	6.038 cm
Unit Type of Package 2	S02
Number of Units in Package 2	100
Package 2 Weight	5.79 kg
Package 2 Height	15 cm
Package 2 width	30 cm
Package 2 Length	40 cm
Unit Type of Package 3	PAL
Number of Units in Package 3	2000
Package 3 Weight	111000 g
Package 3 Height	60 cm
Package 3 width	80 cm
Package 3 Length	90 cm
