Schneider Electric Harmony XAP, XB2 SL, Empty control station, zinc alloy, yellow, M20, 1 cut-out 22mm, 80 x 80 x 51,5, UL cULus; XAPK1201
Harmony XAP, XB2 SL, Empty control station, zinc alloy, yellow, M20, 1 cut-out 22mm, 80 x 80 x 51,5, UL cULus...
VAT-exclusive price: 6.591,00 |
VAT-inclusive price: 7.909,20 |
Harmony XAP, XB2 SL, Empty control station, zinc alloy, yellow, M20, 1 cut-out 22mm, 80 x 80 x 51,5, UL cULus
| range of product | Harmony XAP |
|---|---|
| product or component type | Die-cast empty control station |
| device short name | XAPK |
| product destination | For Ø 22 mm control and signalling units |
| product front plate size | 80 x 80 mm |
| usable depth | 49 mm |
| number of cut-out | 1 cut-out |
| colour of base of enclosure | Yellow (RAL 1004) |
| colour of cover | Yellow (RAL 1004) |
| material | Die cast zinc |
| sale per indivisible quantity | 1 |
| IP degree of protection |
IP65 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 IP66 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 IP69 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 |
| number of vertical rows | 1 |
|---|---|
| number of horizontal rows | 1 |
| cut-out dimensions | Ø 22 mm |
| control station type | Metal |
| cable entry | 2 x cable gland conforming to ISO |
| thread type | M20 x 1.5 |
| CAD overall width | 80 mm |
| CAD overall height | 80 mm |
| CAD overall depth | 51.5 mm |
| net weight | 0.455 kg |
| protective treatment | TC |
|---|---|
| ambient air temperature for storage | -40…70 °C |
| ambient air temperature for operation | -25…70 °C |
| electrical shock protection class | Class I conforming to EN/IEC 61140 |
| degree of protection |
UL type 4 conforming to UL 50 E UL type 4X conforming to UL 50 E |
| IK degree of protection | IK07 conforming to EN/IEC 62262 |
| resistance to chemical agents | Special treatment can be obtained on request |
| product certifications |
UL cULus EAC |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 541.0 g |
| Package 1 Height | 8.0 cm |
| Package 1 width | 8.5 cm |
| Package 1 Length | 9.0 cm |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 12 |
| Package 2 Weight | 6.753 kg |
| Package 2 Height | 15.0 cm |
| Package 2 width | 30.0 cm |
| Package 2 Length | 40.0 cm |
