Name: Schneider Electric Easypact CVS - CVS100F TM63D prekidač - 3P/3d;LV510335
Brand: Schneider Electric
SKU: LV510335
Price: 14504.40 RSD
Availability: OutOfStock

Schneider Electric Easypact CVS - CVS100F TM63D prekidač - 3P/3d;LV510335

Circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 3P 3d...

Brand: Schneider Electric
Product Code: LV510335
Availability: Check availability

VAT-exclusive price: 12.087,00

VAT-inclusive price: 14.504,40

Qnt:

Circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 3P 3d

Main
range of product	Easypact CVS100...250
product or component type	Circuit breaker
device short name	CVS100F
device application	Distribution
poles description	3P
protected poles description	3d
Earth leakage protection (Vigi add on)	Without
[In] rated current	100 A at 40 °C
breaking capacity code	F
network type	AC
[Icu] Breaking capacity	36 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 70 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
utilisation category	Category A
trip unit name	TM-D
trip unit technology	Thermal-magnetic
trip unit rating	63 A at 40 °C
protection type	Short-circuit protection (magnetic) Overload protection (thermal)

Complementary
network frequency	50/60 Hz
control type	Toggle
mounting mode	Fixed
mounting support	Backplate
upside connection	Front
downside connection	Front
connections - terminals	Screw connection
[Uimp] rated impulse withstand voltage	8 kV conforming to EN/IEC 60947-2
thermal protection adjustment range	44.1…63 A
[Ics] rated service breaking capacity	18 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 36 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 70 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
mechanical durability	30000 cycles
electrical durability	12000 cycles 415 V In conforming to IEC 60947-2
connection pitch	35 mm
contact position indicator	Yes
long time pick-up adjustment type Ir	Adjustable
long time pick-up adjustment range	0.7...1 x In
long time delay adjustment type	Fixed
instantaneous pick-up adjustment type Ii	Fixed
instantaneous pick-up adjustment range	500 A
height	161 mm
width	105 mm
depth	86 mm
net weight	1.8 kg

Environment
electrical shock protection class	Class II
standards	EN 60947-2 IEC 60947-2
product certifications	GOST IEC
IP degree of protection	IP40
pollution degree	3 conforming to IEC 60664-1
