Schneider Electric ClimaSys CC - jednostavni termostat 250V - opseg 0…60°C - NC - °F; NSYCCOTHCF
ClimaSys CC - simple thermostat 250V - range of temperature 0…60°C - NC - °F...
VAT-exclusive price: 2.121,00 |
VAT-inclusive price: 2.545,20 |
ClimaSys CC - simple thermostat 250V - range of temperature 0…60°C - NC - °F
| range |
ClimaSys
|
|
|---|---|---|
| product name |
ClimaSys CC
|
|
| product or component type |
Simple thermostat
|
|
| temperature setting range |
0…60 °C
|
|
| information displayed |
Temperature in °F
|
| input voltage |
250 V
|
|
|---|---|---|
| sensor type |
Bimetal
|
|
| contacts type and composition |
NC
|
|
| contact resistance |
10 mOhm
|
|
| service life in cycles |
100000 cycles
|
|
| maximum switching capacity |
2 A 120...250 V AC inductive pf: 0.6
10 A 250 V AC resistive 15 A 120 V AC resistive 30 W DC |
|
| electrical connection |
4 terminals, clamping capacity: 2.5 mm²
|
|
| mounting mode |
Clipped
|
|
| height |
68 mm external:
|
|
| width |
33 mm external:
|
|
| depth |
44 mm external:
|
|
| net weight |
40 g
|
|
| mounting location |
On mounting plate
35 mm DIN rail Cross rails Spacial upright |
|
| ambient air temperature for operation |
-20…80 °C
|
|
| IP degree of protection |
IP20
|
|
| hysteresis |
7 %
|
|
| number of outputs |
1 heating function
|
|
| material |
PC
|
|
| colour |
Light grey
|
|
| flame retardance |
Self-extinguishing conforming to UL94 (material V0)
|
|
| product certifications |
UL
|
| Unit Type of Package 1 |
PCE
|
|
|---|---|---|
| Number of Units in Package 1 |
1
|
|
| Package 1 Weight |
65.333 g
|
|
| Package 1 Height |
4.5 cm
|
|
| Package 1 width |
6 cm
|
|
| Package 1 Length |
8 cm
|
| REACh Regulation | ||
|---|---|---|
| REACh free of SVHC |
Yes
|
|
| EU RoHS Directive |
Compliant
EU RoHS Declaration |
|
| Mercury free |
Yes
|
|
| RoHS exemption information | ||
| China RoHS Regulation |
China RoHS declaration
Product out of China RoHS scope. Substance declaration for your information |
| Warranty |
18 months
|
|---|
-
ClimaSys CC NSYCCOTHCF
