Name: Schneider Electric Baterija - 24 V DC - 75 A - 7 Ah;ABL8BPK24A12
Brand: Schneider Electric
SKU: ABL8BPK24A12
Price: 41391.60 RSD
Availability: OutOfStock

Schneider Electric Baterija - 24 V DC - 75 A - 7 Ah;ABL8BPK24A12

Battery - 24 V DC - 75 A - 7 AH - for battery control module...

Brand: Schneider Electric
Product Code: ABL8BPK24A12
Availability: Check availability

VAT-exclusive price: 34.493,00

VAT-inclusive price: 41.391,60

Qnt:

Battery - 24 V DC - 75 A - 7 AH - for battery control module

Main
range of product	Phaseo
product or component type	Battery module
input voltage	24 V DC
output voltage	24 V DC
maximum output current	75 A
battery capacity	12 Ah
holding time	< 20 h at 0.6 A, 20 °C > 5 min at 31.3 A, 20 °C

Complementary
input voltage limits	21...29 V
charging time	72 h
load current	1.2 A
output protection type	Against overload and short-circuits, protection technology: 2 x 30 A automotive type fuses
connections - terminals	For input connection: screw type terminals, connection capacity: 4 x 0.5...4 x 10 mm² AWG 20...AWG 8 For output connection: screw type terminals, connection capacity: 4 x 0.5...4 x 10 mm² AWG 20...AWG 8
self-discharge rate	15 %, 6 months 9 %, 3 months 3 %, 1 month
fixing mode	By 2 screws diameter: 5 mm on horizontal panel, operating position: horizontal By 4 screws diameter: 5 mm on vertical panel, operating position: vertical
output coupling	Parallel
operating altitude	2000 m
service life in hours	11000 h at 40 °C 15000 h at 35 °C 22000 h at 30 °C 31000 h at 25 °C 44000 h at 20 °C 5000 h at 50 °C 7300 h at 45 °C
marking	CE
net weight	12 kg

Environment
product certifications	UL EAC
ambient air temperature for operation	0…40 °C
ambient air temperature for storage	-20…50 °C
IP degree of protection	IP10 conforming to EN/IEC 60529
overvoltage category	Class 3 conforming to VDE 0106-1
vibration resistance	2 gn (f= 11.9…150 Hz) conforming to EN/IEC 61131-2 3.5 mm (f= 3…11.9 Hz) conforming to EN/IEC 61131-2

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Weight	10.736 kg
Package 1 Height	18.8 cm
Package 1 width	32.8 cm
Package 1 Length	20.2 cm
Unit Type of Package 2	CAR
Number of Units in Package 2	1
Package 2 Weight	10.455 kg
Package 2 Height	19 cm
Package 2 width	20 cm
Package 2 Length	23 cm
Unit Type of Package 3	S06
Number of Units in Package 3	10
Package 3 Weight	117.55 kg
Package 3 Height	73.5 cm
Package 3 width	60 cm
Package 3 Length	80 cm
