Name: Schneider Electric Baterija - 24 V DC - 32 A - 3.2 Ah;ABL8BPK24A03
Brand: Schneider Electric
SKU: ABL8BPK24A03
Price: 25923.60 RSD
Availability: OutOfStock

Schneider Electric Baterija - 24 V DC - 32 A - 3.2 Ah;ABL8BPK24A03

Battery- 24 V DC - 32 A - 3.2 AH - for battery control module...

Brand: Schneider Electric
Product Code: ABL8BPK24A03
Availability: Check availability

VAT-exclusive price: 21.603,00

VAT-inclusive price: 25.923,60

Qnt:

Battery- 24 V DC - 32 A - 3.2 AH - for battery control module

Main
range of product	Phaseo
product or component type	Battery module
input voltage	24 V DC
output voltage	24 V DC
maximum output current	32 A
battery capacity	3.2 Ah
holding time	< 20 h at 0.16 A, 20 °C > 5 min at 8.4 A, 20 °C

Complementary
input voltage limits	21...29 V
charging time	72 h
load current	0.3 A
output protection type	Against overload and short-circuits, protection technology: 1 x 20 A automotive type fuse
connections - terminals	For input connection: screw type terminals, connection capacity: 2 x 0.5...2 x 10 mm² AWG 20...AWG 8 For output connection: screw type terminals, connection capacity: 2 x 0.5...2 x 10 mm² AWG 20...AWG 8
self-discharge rate	9 %, 3 months 3 %, 1 month 15 %, 6 months
fixing mode	By 2 screws diameter: 5 mm on horizontal panel, operating position: horizontal By 4 screws diameter: 5 mm on vertical panel, operating position: vertical By clips (with mounting kit) on 35 mm symmetrical DIN rail, operating position: horizontal By clips (with mounting kit) on 35 mm symmetrical DIN rail, operating position: vertical
output coupling	Parallel
operating altitude	2000 m
service life in hours	11000 h at 40 °C 15000 h at 35 °C 22000 h at 30 °C 31000 h at 25 °C 44000 h at 20 °C 5000 h at 50 °C 7300 h at 45 °C
marking	CE
net weight	3.5 kg

Environment
product certifications	EAC UL
ambient air temperature for operation	0…40 °C
ambient air temperature for storage	-20…50 °C
IP degree of protection	IP10 conforming to EN/IEC 60529
overvoltage category	Class 3 conforming to VDE 0106-1
vibration resistance	2 gn (f= 11.9…150 Hz) conforming to EN/IEC 61131-2 3.5 mm (f= 3…11.9 Hz) conforming to EN/IEC 61131-2

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Weight	3.644 kg
Package 1 Height	17.8 cm
Package 1 width	27.2 cm
Package 1 Length	17 cm
Unit Type of Package 2	CAR
Number of Units in Package 2	1
Package 2 Weight	3.866 kg
Package 2 Height	17.5 cm
Package 2 width	16.5 cm
Package 2 Length	26.8 cm
Unit Type of Package 3	S06
Number of Units in Package 3	24
Package 3 Weight	105.784 kg
Package 3 Height	73.5 cm
Package 3 width	60 cm
Package 3 Length	80 cm
