Schneider Electric 130mm rotirajuća svetiljka crvena 230VAC IP67;XVR13M04L

Harmony XVR, Rotating beacon, Ø130, red, without buzzer, 230 V AC...

Brand: Schneider Electric
Product Code: XVR13M04L
Availability: Check availability

VAT-exclusive price: 38.672,00

VAT-inclusive price: 46.406,40

Qnt:

Description
Specification

Harmony XVR, Rotating beacon, Ø130, red, without buzzer, 230 V AC

Main
range of product	Harmony XVR
product or component type	Prewired rotating mirror beacon
sound signalling	Without
device short name	XVR
mounting diameter	130 mm
IP degree of protection	IP66 conforming to IEC 60529 IP67 conforming to IEC 60529
[Us] rated supply voltage	230 V AC
light source	High luminosity LED, red

Complementary
material	ABS (acrylonitrile butadiene-styrene): body part PC: globe
CAD overall width	130 mm
CAD overall depth	130 mm
net weight	0.99 kg
marking	CE
product mounting	By 3 M6 screws
[Uimp] rated impulse withstand voltage	4 kV
current consumption	22 mA
flashing frequency	2.7 Hz
clamping connection capacity	1.25 mm²
AWG gauge	AWG 18
cable length	400 mm

Environment
standards	EN/IEC 60947-5-1 EN/IEC 60947-1
protective treatment	TC
ambient air temperature for storage	-35…70 °C
ambient air temperature for operation	-30…50 °C
electrical shock protection class	Class II conforming to IEC 61140

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Weight	1.336 kg
Package 1 Height	19.0 cm
Package 1 width	19.0 cm
Package 1 Length	27.5 cm
Unit Type of Package 2	P06
Number of Units in Package 2	24
Package 2 Weight	45.572 kg
Package 2 Height	77.0 cm
Package 2 width	80.0 cm
Package 2 Length	60.0 cm
Unit Type of Package 3	S04
Number of Units in Package 3	6
Package 3 Weight	9.35 kg
Package 3 Height	30.0 cm
Package 3 width	40.0 cm
Package 3 Length	60.0 cm
